NUCLEO Universal E-Ink Driver Shield Hat for Arduino UNO XNUCLEO Supports Various Waveshare SPI e-Paper Raw Panel Modules Compatible with 3.3V/5V MCUs Leonardo

Universal E-Ink Driver Shield Hat for Arduino UNO, Leonardo, NUCLEO, XNUCLEO Supports Various Waveshare SPI e-Paper Raw Panel Modules Compatible with 3.3V/5V MCUs: Computers & Accessories. Buy Universal E-Ink Driver Shield Hat for Arduino UNO, Leonardo, NUCLEO, XNUCLEO Supports Various Waveshare SPI e-Paper Raw Panel Modules Compatible with 3.3V/5V MCUs: Motherboards - ✓ FREE DELIVERY possible on eligible purchases. This is a universal driver board for connecting Arduino/NUCLEO and e-Paper raw panels, can be used to drive various SPI interface e-Paper from Waveshare 。 Onboard external RAM, more available space 。 Onboard voltage translator, compatible with 3.3V/5V MCUs 。 Micro SD slot, images can be stored on TF card for displaying 。 Comes with development resources and manual (examples for Arduino/STM32), download: www.waveshare.com/wiki/e-Paper_Shield 。 Description。 。 This is a universal driver board for connecting Arduino/NUCLEO and e-Paper raw panels, can be used to drive various SPI interface e-Paper from Waveshare.。 。 。 Features。 。 Standard Arduino connectivity, compatible with host boards like UNO, Leonardo, NUCLEO, XNUCLEO。 Onboard voltage translator, compatible with 3.3V/5V MCUs。 Onboard external RAM, more available space。 Micro SD slot, images can be stored on TF card for displaying。 Reserved control interface, for connecting with other control boards。 Comes with development resources and manual (examples for Arduino/STM32)。 。 。 Specifications。 。 Operating voltage: 3.3V/5V。 Interface: 3-wire SPI, 4-wire SPI (default)。 Outline dimension: 53.34mm × 53.34mm。 。 。 Package Content。 。 1. e-Paper Shield x1。 2. e-Paper Adapter x1。 3. 24PIN FFC x1。 。 。 。
